Features:
- Designed for FTTH networks
- No power required
- Zinc die-cast housing, rickel-plated
- Small size and easy installation
Specification:
| Optical Parameter: | ||
| Optical Connector | SC/APC | |
| Responsivity | ≥0.9A/W | |
| Input Optical Power | -10~0dBm | |
| Optical Return Loss | ≥45dB | |
| Input Wavelength | Without filter | 1260~1600nm |
| With filter | 1550±20nm | |
| Optical Fiber Type | Single mode | |
| RF Parameter: | ||
| RF Connector | F-female | |
| Frequency Range | 47~1000MHz | |
| Flatness | ±1dB | |
| Output Level | ≥58dBuV @ -1dBm | |
| Output Impedance | 75Ω | |
