The CENTRAL SEMICONDUCTOR CSHD6-100C is a Silicon Schottky Rectifier designed for surface mount high voltage applications requiring a low forward voltage drop.
- MAXIMUM RATINGS: (TC=25°C unless otherwise noted)
- Peak Repetitive Reverse Voltage VRRM 100 V
- Average Rectified Forward Current (TC=120°C) IO 6.0 A
- Peak Forward Surge Current (tp=10ms) IFSM 50 A
- Peak Repetitive Reverse Surge Current (tp=2ms) IRRM 1.0 A
- Critical Rate of Rise of Reverse Voltage dv/dt 10,000 V/ms
- Operating and Storage Junction Temperature TJ, Tstg -65 to +150 °C
- Thermal Resistance QJC 3.5 °C/W
Benefits
- Optimized for Logic Level Drive Very Low RDS(ON) at 4.5V VGS Superior R*Q at 4.5V VGS Improved Gate
- Avalanche and Dynamic dV/dt Ruggedness Fully Characterized Capacitance
- Avalanche SOA Enhanced body diode dV/dt and dI/dt Capability Lead-Free TO-2
