HAP SERIES

1,775.00

Setup

  • Choose your powering solution, please see the Powering section for possibilities.
  • Connect your internet cable to the first port, and, if you have wired devices, connect them to the other ports
  • Set your computer IP configuration to automatic (DHCP).
  • From your PC or smartphone, connect to the wireless network name which starts with “MikroTik”.
  • Once connected to the wireless network, open https://192.168.88.1 in your web browser to start configuration, user name: admin and there is no password by default (or, for some models, check user and wireless passwords on the sticker)..
  • When using a mobile application choose Quick setup and it will guide you through all necessary configuration in six easy steps.
  • We recommend clicking the “Check for updates” button and updating your RouterOS software to the latest version to ensure the best performance and stability.
  • Choose your country, to apply country regulation settings and set up your password on the screen that loads.

Powering

The device accepts powering from the microUSB port. The port itself doesn’t function as a standard microUSB port for data, it is only used for power. You can use any standard 0.5 – 2A USB adapter that usually comes with smartphones. One 5V 0.7A USB charger is included in the box.
The power consumption under maximum load can reach 3.5W.

Category:

The hAP is a simple home wireless access point. It is already configured, you can simply plug in your ISP cable and start using wireless internet. We recommend you set up a password to secure your device.

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing accidents.
Ultimate disposal of this product should be handled according to all national laws and regulations.
The Installation of the equipment must comply with local and national electrical codes.
This unit is intended to be installed in the rackmount. Please read the mounting instructions carefully before beginning installation. Failure to use the correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage to the system.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity or hot environments.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
Read the installation instructions before connecting the system to the power source.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.
It is the customer’s responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed.
This is a class A device. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate measures.

Exposure to Radio Frequency Radiation: This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an uncontrolled environment. This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the general public.
