GPON ZC-520

₹1,800.00

Specifications

Technical item ZC-520 XPON 1GE+3FE+1USB+1POTS+WiFi
PON 1 G/EPON port (EPON PX20+ and GPON Class B+)

Receiving sensitivity: ≤-28dBm

Transmitting optical power: 0~+4dBm

Transmission distance: 20KM
LAN Auto-adaptive 10 Mbit/s, 100 Mbit/s or 1000 Mbit/s,MAC address learning
POTS . SIP/ H.248
. Call waiting, inconditional Call Forward, Call Forward if Busy, Call Forward if no reply and Three-party calls.
. G.711A/U, G.729 and G.722 encoding/decoding
. T.30/T.38/G.711 fax mode
. SDP protocol (RFC 2327 and RFC 4566)
. DTMF
WiFi Feature . IEEE 802.11 b/g/n (2.4G)
. 2 × 2 MIMO
. Antenna gain: 5 d Bi, double external antenna
. Air interface rate:300 Mbit/s
. WMM
. Multiple SSIDs
. WPS
USB 1xUSB2.0 for storage
LED 12, For Status of Power, PON, LOS, LAN1~4 ,TEL,USB,WiFi,WPS.
Operating condition Temperature: 0℃～+50℃

Humidity: 5%～90%(non-condensing)

Storing

condition

 Temperature: -30℃～+75℃

Humidity :5%～90%(non-condensing)
Power supply DC 12V,1/1.5A
Power consumption ≤10W
Dimension 3.5CM*16.3CM*11.4CM(L×W×H)
Net weight 0.25Kg



Categories: ,
Add to wishlist

ZC-520 G/EPON ONT terminal includes 1GE+3FE,1POTS,2.4GHz WiFi and USB port for storage. It supports Dual modes which can work with both EPON and GPON OLT device. In addition, ZC-520 can also be applied to a wide temperature environment, and also has a powerful firewall .



G/EPON 1GE+3FE+1USB+1POTS+WiFi ONU is perfect for usage of telecom operators, FTTO (office), FTTD (Desk), FTTH(Home) , SOHO, video surveillance and other requirements. The zc-520 is based on the mature Gigabit XPON technology, highly reliable and easy to manage, with guaranteed QOS for different services. And it is fully compliant with technical regulations such as ITU-T G.984.x and IEEE802.3ah.SFP with SC/UPC ConnectorTransceiver.
