Media Converter

FEATURES:

1.25Gbps SFP Bi-Directional Transceiver, 80KM Reach Tx1550nm/Rx1490nm
 Dual data-rate of 1.25Gbps/1.063Gbps operation
 1550nm DFB laser and PIN photodetector for 80KM transmission
 Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
 Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
 Compatible with SONET OC-24-LR-1
 Compatible with RoHS
 +3.3V single power supply
 Operating case temperature range:
0 °C to +70 °C (Commercial)
-40 °C C to +85 °C (Industrial)

Applications:
 Gigabit Ethernet
 Fiber Channel
 Switch to Switch interface
 Switched backplane applications
 Router/Server interface
 Other optical transmission system

Features

Dual data-rate of 1.25Gbps/1.063Gbps operation
 1490nm DFB laser and PIN photodetector for 80KM transmission
 Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
 Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
 Compatible with SONET OC-24-LR-1
 Compatible with RoHS
 +3.3V single power supply
 Operating case temperature range:
0 °C to +70 °C (Commercial)
-40 °C to +85 °C (Industrial)

Applications
 Gigabit Ethernet
 Fiber Channel
 Switch to Switch interface
 Switched backplane applications
 Router/Server interface
 Other optical transmission systems

Features

• Hot-Pluggable SFP package
• Up to 1.25Gb/s data links
• Compliant with SFP MSA standard
• Compliant with IEEE 802.3z
• Single LC Connector
• Single 3.3V power supply
• Low power dissipation
• The metal enclosure provides lower EMI
• ROHS compliant and Lead-Free
• Digital Diagnostic Monitor Interface

Specification

Features
 Dual data-rate of 1.25Gbps/1.063Gbps operation
 1550nm FP laser and PIN photodetector for 3km transmission
 Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
 Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
 Compatible with SONET OC-24-LR-1
 Compatible with RoHS
 +3.3V single power supply
 Operating case temperature range:
0 °C to +70 °C (Commercial)
-40 °C to +85 °C (Industrial)

Applications
 Gigabit Ethernet
 Fiber Channel
 Switch to Switch interface
 Switched backplane applications
 Router/Server interface
 Other optical transmission systems

Modelo Del Producto:ES5512-3LCD120
Velocidad De Datos:1.25G
Longitud De Onda:1550nm
Distancia:120KM
Conector:LC
Tipo De Fibra:SM
DDM:YES

SFP MSA package with Single LC connector
Very low EMI and excellent ESD protection
Digital Diagnostic Monitor Interface
Hot pluggable
10Gb/s serial optical interface
Up to 10km distance
Compliant with SFP+ MSA
High transmission margin
+3.3V single power supply
Below 0.8W power consumption
SFP mechanical interface

Features

• Hot-pluggable SFP+ footprint
• Electrical interface compliant to SFF-8431
• Compliant with SFF-8472
• 10Gb/s serial optical interface compliant to 802.3ae 10GBASE-LR
• 1330nm DFB transmitter, 1270nm PIN photo-detector
• Distance up to 20km on single mode fiber
• LC Simplex connector
• Built-in digital diagnostic functions
• Single 3.3V power supply
• Metal enclosure, for lower EMI
• ROHS compliant and lead-free

Specification

FEATURES:

10Gbps SFP+ Bi-Directional Transceiver, 60km Reach
 Tx1270/1330nm / Rx1330/1270nm
 Supports 9.95Gb/s to 10.3Gb/s data rates
 Simplex LC Connector Bi-Directional SFP+ Optical Transceiver
 Single 3.3V Supply
 Up to 60km on 9/125um SMF
 A:1270nm DFB Laser transmitter,1330nm APD receiver
 B:1330nm DFB Laser transmitter,1270nm APD receiver
 SFP+ MSA SFF-8431 Compliant
 Digital Diagnostic SFF-8472 Compliant
 RoHS compliant and Lead Free
 Operating case temperature:
 Standard: 0 ~ 70 °C

Applications:
 10GBASE-LR at 10.3125Gbps
 10GBASE-LW at 9.953Gbps
 Other Optical

Features

Specification

 Features:

• Optimized Power: With a power level of 9 dBm, this HO GPON SFP module ensures efficient data transmission, making it ideal for a wide range of GPON network setups and applications.
• Optical Connectivity: Designed for GPON networks, this module offers optical connectivity to enhance network reach and efficiency.
• High Performance: Built for robust and consistent performance, this module enhances your network’s capabilities and efficiency.

  Product Details:

  • Type:  GPON SFP C+++ 9 dBm Transceiver Module
  • Power Level: 9 dBm
  • Optical Connectivity: GPON network compatibility
  • High Performance: Built for reliability and consistency

PRODUCT FEATURES :

1. Single LC receptacle optical interface compliant
2. Hot-pluggable SFP footprint
3. 1310nm FP laser transmitter ; 1550nm DFB laser transmitter
4. 1310nm FP laser transmitter；1490nm DFB laser transmitter
5. RoHS compliant and Lead Free
6. Up to 40km on 9/125um SMF
7. Metal enclosure for lower EMI
8. Single 3.3V power supply
9. Low power dissipation <600mW
10. Commercial operating temperature range: 0°C to 70°C

APPLICATIONS :

Gigabit Ethernet

1.06 Gb/s Fibre Channel

Type

SFP

Mode

Single Mode

Rate

1.25G

Wavelenght

TX1550/RX1310

Connectivity With

1 FO

Maximum Length

20km

Connector Type

Single LC
